Trigonometry
Sin, Cosine, Tan
Examples
Have a Go
Practice Questions



Back to
Trigonometry Units

Trigonometry is a branch of mathematics that means "measurement of, with and by means of triangles".

Astronomers as early as 150 BC developed the study of trigonometry.  By about 1500 AD the trig. ratios (sine, cosine and tangent) were established.  Once again, right-angled triangles, as in Pythagoras' Theorem,  are important when making calculations with the trig ratios.





Example

The Navigator's Problem

A ship travels 10 km on a course heading 50 east of north.
How far north,  and how far east has the ship travelled at this point?



Return to Top of Page





Have a Go

Problem 1

The base of the right-angled triangle shown is 5 cm in length,  and the angle A is 60.
Calculate the altitude BC.







See Solution





Problem 2

Use Pythagoras' theorem to find the missing sides of these right-angled triangles.

Use these triangles to complete the following table.

  30 45 60
sin
cos
tan

See Solution



Return to Top of Page



Practice Questions

Question 1

A railway is inclined at an angle of 1 to the horizontal.  Find the vertical height climbed when a train travels 1 km up the hill.



Question 2

Find  "a" in the following triangles (leave your answers in surd form):

Use the table in Practice Question 2.

Click to see Answer

Question 3

The foot of a ladder is 1.5 m from  a vertical wall.  The ladder makes an angle of 68 with the horizontal.  How far up the wall does the ladder reach?



Question 4

The string of a kite is 120 m long and makes an angle of 70 with the horizontal.  What is the height of the kite?



Return to Top of Page





Answer to Practice Question 2





Return to Practice Questions















Solution 1

back to Have a Go

Solution 2




  30 45 60
sin
cos
tan 1



back to Have a Go

Return to Top of Page
